EQUIPMENT设备
● 热收缩炉
主机尺寸：1800L x 500W x 600H m可升降调节
内循环风
重量：约 200kg
电压 : 3 相 380 V
总功率：9KW
耐高温框体
可适应不同形状，尺寸产品
适应收缩膜材质 PVC, PET, OPS
温度精度控制范围 +/- 2 度
全程均匀收缩
EQUIPMENT 设备
HEAT SHRINK TUNNEL 热收缩炉
ELECTRICAL TUNNEL PF-E1800 电热收缩炉 PF-E1800
TECHNICAL PARAMETER
Main machine size: 1800L x 500W x 600H mm
Tunnel Auto Up and Down
Blow Air Frequency Controlled
Weight: about 200kg (main machine)
Voltage: 3 phase 380 / 220V
Blower power: 9KW
Heat-resistant paint structure
Easy to install and operation, adjustment is convenient when change the product
Electric Heat Shrink Tunnel is suitable for PVC, PET, OPS shrink packaging materials use
Suitable for shrink variety bottle shapes, circle, square, oval-shaped, and curve-shaped etc
Accurately temperature control with +/- 5 degree
Achieve variety bottle shapes and product request by unique diversion wind force inside
After shrinkage, the outside of the products is free of any trace of water-drops and products can be conveyed for
further package direct
